STANDARD EQUIPMENT
- Conforms to CE regulations.
- Pendular cutting system.
- Upper blade 2 sides.
- Lower blade 4 sides.
- Automatic blade adjustment by means of NC-ELGO with 10 memories.
- Electric pedal with emergency stop.
- T-slotted square console with retractable internal stops.
Opportunity: GARNET Hydraulic Shear mod. GPR-2606 NC, second hand machine. Ref. 428
FEATURES
- Cutting length 2,600 mm
- Cutting capacity (ST 42) 6 mm
- Back gauge 1,000 mm
- Cutting angle 1.2º.
- Strokes per minute 24
- of hold down 12
- Main motor 15 Kw.
- Back gauge motor 0,75 Kw.
- Table length 2.900 mm
- Total length 3.500 mm
- Total width 3.010 mm
- Transport width 2.100 mm
- Total height 1.640 mm
- Weight 5.000 Kg.
